Bypass FRP Lava Z61 (FRP Unlock) Fix Tool DL Image Failed

If you own a Lava Z61, and after the hard reset if you stuck at google account verification screen then here we will solve your problem by unlocking FRP lock from your device, so just follow this process to Bypass FRP Lava Z61 very easily, there is a couple of methods to unlock FRP from your device but we share here the latest and easiest method to Unlock FRP Lava Z61.

This phone has some strong features, the front camera of this phone is good enough to provide crisp and clear selfies and the storage of this device is sufficient enough to store a big amount of images, videos and kinds of music, Redmi 5a has a decent processor and RAM management is very good while you do multitasking with this device.

Things That you Needed to Unlock FRP Lava Z61

You can follow this method on any Z61, Only you need a good internet connection and download some files To Bypass FRP Lava Z61.

Warning:- This method is only for the device owner.

Note:- This method is successfully applied to Lava Z61.

Caution:- We are not responsible for any damage to your Device. before you try this method backup your Full data.

  • -Download the first DA File:- (Download Agent) file that helps you to detect your device in SP Flash Tool.
  • -Z61 FRP Tool:- It’s a new tool to remove frp.
  • -Download & Install Qualcomm USB Driver.
  • -Follow the below guide carefully.

Download (Mega)

Download Lava Z61 FRP Unlock File

File Name:-Lava_Z61_FRP_Unlock.zip

Download

Download (Mega)

Now install MTK USB Driver to Computer:

  • -Open the “USB Driver” folder, there you will see a “setup.exe” file.
  • -Install the “Setup.exe” file by double tapping on it.
  • -Then hit next -next-next -finish to install the MTK driver to your computer.
  • -Done. now your device will easily detect on PC and you can easily do the Unlock FRP Itel A45.

How to Bypass FRP Lava Z61

  • -First, you have to download all the frp files and tool to your computer.
  • -Once downloading finish, copy all the files to a new folder. (to understand easily).
  • -After that, extract all the downloaded files one by one using 7zip or WinRAR.
  • -Once done, now there you will see “3” folders. <i> FRP Files, <ii> FRP tools, <iV> DA  File.
  • -Extract “FRP Tool” and “FRP File” on your PC.
  • -Then open the FRP tool folder.
  • -There you can see “SP Flash Tool” folder.
  • -Open “SP Flash Tool” folder.
  • -Then find and Run as Administrator “SP Flash Tool.exe”.

  • -After that, Goto “Download” tab.
  • -Now Click on the “Choose” from the “Download-Agent” that helps you to configure your device in the SP flash tool.
  • -Now Give the file path of boot file “Lava Z61 DA.bin”. – file on extracted frp files folder.
  • -Then click on “Choose” from “Scatter-loading File”
  • -Now give there file path of “Scatter.txt” file from the “FRP File” folder.
  • -Go to the format tab to Bypass FRP Lava Z61 (See Below image).

-Select “Manual Format Flash” from that tab.

  • -Give the below address from that box. (or you can find Address also in your FRP File by Gadgetsdr folder).

-start_addr: 0x2d88000
-End_addr: 0x100000

  • -After changing the value, you have to connect your device to PC to successfully Unlock FRP Lava Z61.

Now Connect your device to successfully unlock FRP

  • -Power off your device.
  • -Now connect your device to PC.
  • -While connecting press (Volume Down) key, and connect your device to PC.

Note:- Make sure, before you connect your device to PC, you need to download and install USB Driver first on your PC. when you connect your device to PC keep pressing Volume down key few more seconds after connecting.

  • -After that, Click on “Start” button from sp flash tool to Unlock frp Lava Z61.
  • -Once the flashing process is finished, you will get a “Right exclamation mark” popup.

  • -Now you have successfully Bypass FRP Lava Z61.
  • -Just disconnect your device to PC and Power On your device.
  • Now You will face Tool DL Image Failed issue after the power on your device.
  • -Follow this to fix this.

Fix Tool DL image Failed Lava Z61

  • -Once again open the “SP Flash Tool.exe”.
  • -Then click on the “download” tab.
  • -After that, choose the scatter file and DA file in SP Flash tool.
  • -Then untick the “preloader” option there.
  • -Now click on the “Download” button.
  • -Now power off and then connect your device to PC once again.
  • -wait for the finish.
  • -Once done, power on your device.
  • -now you have successfully Fix Tool DL image Failed Lava Z61.
  • -Thanks for visiting us.
  • -I hope this method is fully worked with your Device.

Subscribe Our Channel For More Interesting Videos Daily (On Youtube):-SUBSCRIBE

Thanks for visiting us, Comment below if you face any problem With This Method, we will try to solve your problem as soon as possible. you can check other some tutorial here to help you.
